Flat Roof House With Wide Eaves Floor Plan

Important: An updated version of these floor plans is available here.

This is a compact two-story modern home with an efficient, rectangle-based footprint and a no-nonsense circulation core. The planning favors open living on the main level and a straightforward three-bedroom arrangement above.

The facade reads as crisp modernist with strong horizontal lines, deep roof overhangs, and a broad band of glazing. Dark panel siding is balanced with warm wood accents for contrast. The garage door is intentionally prominent—because it likes attention. Roofing presents as a low-slope/low-pitch composition with clean fascia lines and restrained detailing.

These floor plans are draft layouts and are available for download as printable PDF. Dimensions and room labels are shown for planning and coordination; final construction documents should refine structure, openings, and services.

Total area: 2,880 sq ft (gross; 48′ × 30′ per floor)
Bedrooms: 3
Bathrooms: 3
Garage
Floors: 2

Main Floor (48′ × 30′ | 1,440 sq ft gross)

Download Floor PDF

A centered entry feeds a short hall and stair, with the living zone opening wide to the rear. Service rooms cluster to the right for tight plumbing runs and sensible utility access. The garage occupies the front-right block, keeping daily arrivals delightfully un-dramatic.

Porch
Entryway
Hall (with stair up)
Living Room
Dining Room
Kitchen (island layout)
Back Hall
Bathroom
Laundry
Utility
Office
Garage
Deck

Upper Floor (48′ × 30′ | 1,440 sq ft gross)

Download Floor PDF

The stair lands at a central hall that distributes cleanly to three bedrooms. Two baths sit near the top-left zone, keeping morning traffic controlled—mostly. Storage is integrated as dedicated closets, not wishful thinking.
